如何通过命令行配置RAID?

发表于 分类于 ，

概述

LSI 公司（LSI Corporation）（NASDAQ：LSI）是一家总部位于加利福尼亚州米尔皮塔斯 (Milpitas) 的半导体和软件领先供应商，其主要产品包括：RAID 控制器、SSD 控制器、ReadChannel、Preamp、Axxia 网络处理器和定制 ASIC 等，为加速数据存储中心与移动网络性能提供了许多领先的解决方案。

在目前各大知名品牌服务器厂商：IBM、DELL、HP、华为、联想、宝德、浪潮、中科曙光等服务器都使用 LSI 品牌的阵列卡作为服务器存储控制器，而且其性能其他品牌 RAID 控制器无与伦比，可见 LSI 阵列卡的优越性。

LSI 阵列卡默认采用基于图形化的 BIOS 界面来管理，服务器在开机自检界面提示按 CTRL+C、CTRL+R、CTRL+H 等组合键进入，可使用鼠标或键盘来完成 RAID 的配置等，这种比较适合少量机器手工配置的场景。如果大量的服务器 RAID 的配置任采用这种方法就显得力不从心了，不过实际上 LSI 官方推出了基于命令行的管理软件来实现对 RAID 控制卡的配置与管理，在操作系统内安装软件，可直接对 RAID 控制卡的管理，同时也可使用带驱动的 Linux 内核+脚本即可实现大量服务器批量化自动配置 RAID 来提高管理效率。

目前 LSI 官方发布的基于 SAS/SATA 控制器 RAID 控制卡产品型号（芯片）有：LSI1064、LSI1086、LSI1078、LSI2008、LSI2208、lSI2308、LSI3008、LSI3108 等。
一般地，支持 RAID 5 的卡，我们称其为阵列卡，都可以使用 LSI 官方提供的 MegaCli、SAS2IRCU 等工具来管理，而不支持 RAID 5 的卡，我们称其为 SAS 卡，使用 lsiutil 工具来管理。HP 的服务器则使用其特有的 hpacucli 工具来管理。

Drive Group and Virtual Drive

With the increasing traffic volume of modern data centers, more data needs to run on a single server. When a single drive is insufficient to support system services in terms of capacity and security, multiple drives need to be combined to serve as a visible drive for external entities to meet service requirements. A drive group is a group of physical drives combined as a whole for external entities. Drive groups are the basis for virtual drives.

A virtual drive is a continuous data storage unit divided from a drive group. A virtual drive can be considered an independent drive. Thanks to certain configuration, a virtual drive can provide higher capacity, security, and data redundancy than a physical drive.

A virtual drive can be:

  • A complete drive group.
  • Multiple complete drive groups.
  • Part of a drive group.
  • Parts of multiple drive groups (a part is divided from every drive group, and these parts form a virtual drive).

Related conventions:

  • A drive group is usually specified as Drive Group (DG for short).
  • A virtual drive is usually specified as Virtual Drive, Virtual Disk (VD for short), Volume, Array, and Logical Device (LD for short).

关于 DG 和 VD 的区别可以看看上面的解释。

检测及修复

型号

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
# 检查存储控制器型号
# lspci | grep "RAID bus controller: LSI Logic / Symbios Logic MegaRAID SAS 1078"
01:00.0 RAID bus controller: LSI Logic / Symbios Logic MegaRAID SAS 1078 (rev 04)

# lspci | grep "RAID bus controller: LSI Logic / Symbios Logic MegaRAID SAS 2108"
84:00.0 RAID bus controller: LSI Logic / Symbios Logic MegaRAID SAS 2108 [Liberator] (rev 05)

# lspci | grep "RAID bus controller: LSI Logic / Symbios Logic MegaRAID SAS 2208"
01:00.0 RAID bus controller: LSI Logic / Symbios Logic MegaRAID SAS 2208 [Thunderbolt] (rev 05)

# lspci | grep "Serial Attached SCSI controller: LSI Logic / Symbios Logic SAS2308"
01:00.0 Serial Attached SCSI controller: LSI Logic / Symbios Logic SAS2308 PCI-Express Fusion-MPT
 SAS-2 (rev 05)

# lspci | grep "RAID bus controller: LSI Logic / Symbios Logic MegaRAID SAS-3 3108"
03:00.0 RAID bus controller: LSI Logic / Symbios Logic MegaRAID SAS-3 3108 [Invader] (rev 02)

# lspci | grep "RAID bus controller: Hewlett-Packard Company"
06:00.0 RAID bus controller: Hewlett-Packard Company Smart Array Controller (rev 04)

03:00.0 RAID bus controller: Hewlett-Packard Company Smart Array Gen8 Controllers (rev 01)

# lspci | grep "RAID bus controller: Adaptec"
01:00.0 RAID bus controller: Adaptec AAC-RAID (rev 09)

# lspci | grep "RAID bus controller: 3ware Inc"
08:00.0 RAID bus controller: 3ware Inc 9690SA SAS/SATA-II RAID PCIe (rev 01)

命令

不同的 RAID 卡，厂商或型号不同，对应的命令也不同，以下是目前已知的检查命令：

Corp Model Cmd
LSI SAS2208 storcli64
LSI SAS2308 sas2ircu
LSI SAS3008 sas3ircu
LSI SAS3108 storcli64
LSI SAS3316 storcli64

示例

storcli64

storcli 已经基本代替了 megacli，官方推荐使用 storcli 管理 RAID

检查 RAID

通过命令 storcli64 /call show 可以得到控制器信息

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
# storcli64 /call show
Controller = 0
Status = Success
Description = None

Product Name = SAS2208
Serial Number = FW-AB2M2K4EXVAWC
SAS Address =  5101b5442bcc7000
Mfg. Date = 00/00/00
System Time = 08/22/2018 15:29:27
Controller Time = 08/22/2018 15:29:47
FW Package Build = 23.28.0-0023
BIOS Version = 5.46.02.2_4.16.08.00_0x06060A05
FW Version = 3.400.95-4061
Driver Name = megaraid_sas
Driver Version = 06.810.08.00
Controller Bus Type = N/A
PCI Slot = N/A
PCI Bus Number = 1
PCI Device Number = 0
PCI Function Number = 0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
Drive Groups = 5

# Drive Groups信息可以由以下命令单独列出
# storcli64 /call /dall show

TOPOLOGY :
========

--------------------------------------------------------------------------
DG Arr Row EID:Slot DID Type  State BT       Size PDC  PI SED DS3  FSpace
--------------------------------------------------------------------------
 0 -   -   -        -   RAID0 Optl  N  744.125 GB dflt N  N   none N
 0 0   -   -        -   RAID0 Optl  N  744.125 GB dflt N  N   none N
 0 0   0   0:0      1   DRIVE Onln  N  744.125 GB dflt N  N   none -
 1 -   -   -        -   RAID0 Optl  N  744.125 GB dflt N  N   none N
 1 0   -   -        -   RAID0 Optl  N  744.125 GB dflt N  N   none N
 1 0   0   0:1      4   DRIVE Onln  N  744.125 GB dflt N  N   none -
 2 -   -   -        -   RAID0 Optl  N  744.125 GB dflt N  N   none N
 2 0   -   -        -   RAID0 Optl  N  744.125 GB dflt N  N   none N
 2 0   0   0:2      3   DRIVE Onln  N  744.125 GB dflt N  N   none -
 3 -   -   -        -   RAID0 Optl  N  744.125 GB dflt N  N   none N
 3 0   -   -        -   RAID0 Optl  N  744.125 GB dflt N  N   none N
 3 0   0   0:3      8   DRIVE Onln  N  744.125 GB dflt N  N   none -
 4 -   -   -        -   RAID5 Optl  N    5.085 TB dflt N  N   none N
 4 0   -   -        -   RAID5 Optl  N    5.085 TB dflt N  N   none N
 4 0   0   0:4      2   DRIVE Onln  N  744.125 GB dflt N  N   none -
 4 0   1   0:5      7   DRIVE Onln  N  744.125 GB dflt N  N   none -
 4 0   2   0:6      9   DRIVE Onln  N  744.125 GB dflt N  N   none -
 4 0   3   0:7      11  DRIVE Onln  N  744.125 GB dflt N  N   none -
 4 0   4   0:8      6   DRIVE Onln  N  744.125 GB dflt N  N   none -
 4 0   5   0:9      5   DRIVE Onln  N  744.125 GB dflt N  N   none -
 4 0   6   0:10     12  DRIVE Onln  N  744.125 GB dflt N  N   none -
 4 0   7   0:11     10  DRIVE Onln  N  744.125 GB dflt N  N   none -
--------------------------------------------------------------------------

DG=Disk Group Index|Arr=Array Index|Row=Row Index|EID=Enclosure Device ID
DID=Device ID|Type=Drive Type|Onln=Online|Rbld=Rebuild|Dgrd=Degraded
Pdgd=Partially degraded|Offln=Offline|BT=Background Task Active
PDC=PD Cache|PI=Protection Info|SED=Self Encrypting Drive|Frgn=Foreign
DS3=Dimmer Switch 3|dflt=Default|Msng=Missing|FSpace=Free Space Present

# 这个地方的PDC就是disk cache, 可选On\Off\Default三种选项, 对应为enbl\dsbl\dflt
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
Virtual Drives = 5

# Virtual Drives信息可以由以下命令单独列出
# storcli64 /call /vall show

VD LIST :
=======

---------------------------------------------------------------
DG/VD TYPE  State Access Consist Cache sCC       Size Name
---------------------------------------------------------------
0/0   RAID0 Optl  RW     Yes     NRWBD -   744.125 GB
1/1   RAID0 Optl  RW     Yes     NRWBD -   744.125 GB
2/2   RAID0 Optl  RW     Yes     NRWBD -   744.125 GB
3/3   RAID0 Optl  RW     Yes     NRWBD -   744.125 GB
4/4   RAID5 Optl  RW     Yes     RaWBD -     5.085 TB 6gRcrbya
---------------------------------------------------------------

Cac=CacheCade|Rec=Recovery|OfLn=OffLine|Pdgd=Partially Degraded|dgrd=Degraded
Optl=Optimal|RO=Read Only|RW=Read Write|B=Blocked|Consist=Consistent|
Ra=Read Ahead Adaptive|R=Read Ahead Always|NR=No Read Ahead|WB=WriteBack|
AWB=Always WriteBack|WT=WriteThrough|C=Cached IO|D=Direct IO|sCC=Scheduled
Check Consistency

# 可以看出有5个VD，VD 0-3为RAID0，State为Optimal，Access Policy为RW，
# Read Policy为NR，Write Policy为WB，Cache Policy为Direct IO
# VD4做了RAID5，Read Policy为Ra，Write Policy为WB，Cache Policy为Direct IO
设置项 可选值
accesspolicy RW RO Blocked RmvBlkd
rdcache RA NoRA
wrcache WT WB AWB
pdcache On Off Default
iopolicy Cached Direct
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
Physical Drives = 12

# Physical Drives信息可以由以下命令单独列出
# storcli64 /call /eall /sall show

PD LIST :
=======

----------------------------------------------------------------------------
EID:Slt DID State DG       Size Intf Med SED PI SeSz Model               Sp
----------------------------------------------------------------------------
0:0       1 Onln   0 744.125 GB SATA SSD N   N  512B INTEL SSDSC2BB800G6 U
0:1       4 Onln   1 744.125 GB SATA SSD N   N  512B INTEL SSDSC2BB800G6 U
0:2       3 Onln   2 744.125 GB SATA SSD N   N  512B INTEL SSDSC2BB800G6 U
0:3       8 Onln   3 744.125 GB SATA SSD N   N  512B INTEL SSDSC2BB800G6 U
0:4       2 Onln   4 744.125 GB SATA SSD N   N  512B INTEL SSDSC2BB800G6 U
0:5       7 Onln   4 744.125 GB SATA SSD N   N  512B INTEL SSDSC2BB800G6 U
0:6       9 Onln   4 744.125 GB SATA SSD N   N  512B INTEL SSDSC2BB800G6 U
0:7      11 Onln   4 744.125 GB SATA SSD N   N  512B INTEL SSDSC2BB800G6 U
0:8       6 Onln   4 744.125 GB SATA SSD N   N  512B INTEL SSDSC2BB800G6 U
0:9       5 Onln   4 744.125 GB SATA SSD N   N  512B INTEL SSDSC2BB800G6 U
0:10     12 Onln   4 744.125 GB SATA SSD N   N  512B INTEL SSDSC2BB800G6 U
0:11     10 Onln   4 744.125 GB SATA SSD N   N  512B INTEL SSDSC2BB800G6 U
----------------------------------------------------------------------------

EID-Enclosure Device ID|Slt-Slot No.|DID-Device ID|DG-DriveGroup
DHS-Dedicated Hot Spare|UGood-Unconfigured Good|GHS-Global Hotspare
UBad-Unconfigured Bad|Onln-Online|Offln-Offline|Intf-Interface
Med-Media Type|SED-Self Encryptive Drive|PI-Protection Info
SeSz-Sector Size|Sp-Spun|U-Up|D-Down|T-Transition|F-Foreign

1
2
3
4
5
6
7
8
9
10
11
12

# BBU信息可以由以下命令单独列出
# storcli64 /call /bbu show

BBU_Info :
========

-----------------------------------------------------------------------
Model  State   RetentionTime Temp Mode MfgDate    Next Learn
-----------------------------------------------------------------------
CVPM02 Optimal 0 hour(s)     21C  0    2015/11/14 2018/08/23  10:48:12
-----------------------------------------------------------------------

创建和删除 RAID

命令功能
创建、删除 RAID。

命令格式

1
storcli64 /c`controller_id` add vd r`level` size=`capacity` drives=`enclosure_id`:`startid-endid`
1
storcli64 /c`controller_id`/v`raid_id` del

参数说明

参数 参数说明 取值
controller_id RAID 卡的 ID –
level 要配置的 RAID 级别 –
capacity 要配置的 RAID 容量 –
enclosure_id 硬盘所在 Enclosure 的 ID –
startid-endid 要加入 RAID 的硬盘的起始和结束 ID –
raid_id 要删除的 RAID 的 ID –

使用指南
无

使用实例

1
2
3
4
5
6
# 创建RAID 0

domino:~# ./storcli64 /c0 add vd r0 size=100GB drives=252:0-3
Controller = 0
Status = Success
Description = Add VD Succeeded
1
2
3
4
5
6
# 删除RAID

domino:~# ./storcli64 /c0/v0 del
Controller = 0
Status = Success
Description = Delete VD Succeeded

设置 RAID 组的 Cache 读写属性

命令功能
设置 RAID 组的 Cache 读写属性。

命令格式

1
storcli64 /c`controller_id`/v`raid_id` set wrcache=`mode`

参数说明

参数 参数说明 取值
controller_id RAID 卡的 ID –
raid_id 待设置的 RAID 的 ID –
mode Cache 读写模式 wt：当磁盘子系统接收到所有传输数据后，控制器将给主机返回数据传输完成信号。
wb：控制器 Cache 收到所有的传输数据后，将给主机返回数据传输完成信号。
awb：在 RAID 卡无电容或电容损坏的情况下，强制使用“wb”模式。

使用指南
无

使用实例

1
2
3
4
5
6
7
8
9
10
11
12
13
# 设置Cache读写模式为“wt”。

domino:~# ./storcli64 /c0/v0 set wrcache=wt
Controller = 0
Status = Success
Description = None
Details Status :
==============
---------------------------------------
VD Property Value Status  ErrCd ErrMsg
---------------------------------------
 0 wrCache  WT    Success     0 -
---------------------------------------

disk cache

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
# 查看disk cache信息
# storcli64 /c0 /dall show
Controller = 0
Status = Success
Description = Show Diskgroup Succeeded


TOPOLOGY :
========

--------------------------------------------------------------------------
DG Arr Row EID:Slot DID Type  State BT       Size PDC  PI SED DS3  FSpace
--------------------------------------------------------------------------
 0 -   -   -        -   RAID0 Optl  N  744.125 GB dflt N  N   none N
 0 0   -   -        -   RAID0 Optl  N  744.125 GB dflt N  N   none N
 0 0   0   0:0      1   DRIVE Onln  N  744.125 GB dflt N  N   none -
 1 -   -   -        -   RAID0 Optl  N  744.125 GB dflt N  N   none N
 1 0   -   -        -   RAID0 Optl  N  744.125 GB dflt N  N   none N
 1 0   0   0:1      4   DRIVE Onln  N  744.125 GB dflt N  N   none -
 2 -   -   -        -   RAID0 Optl  N  744.125 GB dflt N  N   none N
 2 0   -   -        -   RAID0 Optl  N  744.125 GB dflt N  N   none N
 2 0   0   0:2      3   DRIVE Onln  N  744.125 GB dflt N  N   none -
 3 -   -   -        -   RAID0 Optl  N  744.125 GB dsbl N  N   none N
 3 0   -   -        -   RAID0 Optl  N  744.125 GB dsbl N  N   none N
 3 0   0   0:3      8   DRIVE Onln  N  744.125 GB dsbl N  N   none -
 4 -   -   -        -   RAID5 Optl  N    5.085 TB dflt N  N   none N
 4 0   -   -        -   RAID5 Optl  N    5.085 TB dflt N  N   none N
 4 0   0   0:4      2   DRIVE Onln  N  744.125 GB dflt N  N   none -
 4 0   1   0:5      7   DRIVE Onln  N  744.125 GB dflt N  N   none -
 4 0   2   0:6      9   DRIVE Onln  N  744.125 GB dflt N  N   none -
 4 0   3   0:7      11  DRIVE Onln  N  744.125 GB dflt N  N   none -
 4 0   4   0:8      6   DRIVE Onln  N  744.125 GB dflt N  N   none -
 4 0   5   0:9      5   DRIVE Onln  N  744.125 GB dflt N  N   none -
 4 0   6   0:10     12  DRIVE Onln  N  744.125 GB dflt N  N   none -
 4 0   7   0:11     10  DRIVE Onln  N  744.125 GB dflt N  N   none -
--------------------------------------------------------------------------

DG=Disk Group Index|Arr=Array Index|Row=Row Index|EID=Enclosure Device ID
DID=Device ID|Type=Drive Type|Onln=Online|Rbld=Rebuild|Dgrd=Degraded
Pdgd=Partially degraded|Offln=Offline|BT=Background Task Active
PDC=PD Cache|PI=Protection Info|SED=Self Encrypting Drive|Frgn=Foreign
DS3=Dimmer Switch 3|dflt=Default|Msng=Missing|FSpace=Free Space Present

# 上面的PDC就是disk cache, 可选On\Off\Default三种选项, 对应为enbl\dsbl\dflt

# 设定pdcache
storcli /c`x`/v`x` set pdcache=`On`|`Off`|`Default`

自动 rebuild

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
# 使用如下命令检查auto rebuild的信息
# storcli64 /call show autorebuild
Controller = 0
Status = Success
Description = None


Controller Properties :
=====================

------------------
Ctrl_Prop   Value
------------------
AutoRebuild OFF
------------------

# 开启/关闭auto rebuild
storcli /c`x` set autorebuild=<`on`|`off`>

设置启动项

命令功能
设置虚拟磁盘或物理硬盘为启动项。

命令格式

1
2
storcli64 /c`controller_id`/v`vd_id` set bootdrive=on
storcli64 /c`controller_id`/e`enclosure_id`/s`slot_id` set bootdrive=on

参数说明

参数 参数说明 取值
controller_id RAID 卡的 ID –
vd_id 待设置的虚拟磁盘的 ID –
enclosure_id 硬盘所在 Enclosure 的 ID –
slot_id 硬盘槽位号 –

使用指南
无

使用实例

1
2
3
4
5
6
7
8
9
10
11
12
13
# 设置VD0为启动项

domino:~# ./storcli64 /c0/v0 set bootdrive=on
Controller = 0
Status = Success
Description = Noe
Detailed Status :
===============
----------------------------------------
VD Property   Value Staus  ErrCd ErrMsg
----------------------------------------
 0 Boot Drive On    Success    0 -
----------------------------------------
1
2
3
4
5
6
7
8
9
10
11
12
13
# 设置slot 7硬盘为启动项

domino:~# ./storcli64 /c0/e252/s7 set bootdrive=on
Controller = 0
Status = Success
Description = Noe
Controller Properties :
=====================
-------------------
Ctrl_Prop Value
-------------------
BootDrive PD:252_7
-------------------
1
2
3
4
5
6
7
8
# 列出bootdrive信息
storcli /cx show bootdrive

# 指定某组为bootdrive
storcli /cx/vx set bootdrive=<on|off>

# 指定某盘为bootdrive
storcli /cx[/ex]/sx set bootdrive=<on|off>
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
# 检查启动盘
# storcli64 /c0 show bootdrive
Controller = 0
Status = Success
Description = None


Controller Properties :
=====================

----------------
Ctrl_Prop Value
----------------
BootDrive VD:0
----------------

sas2ircu

设置指定 RAID 组作为第一启动项

命令功能
设置指定 RAID 组作为第一启动项。

命令格式

1
sas2ircu `controller_id` bootir `volume_id`

参数说明

参数 参数说明 取值
controller_id RAID 卡的 ID –
volume_id 待设置为第一启动项的 RAID 组 ID –

使用指南
无

使用实例

1
2
3
4
5
6
7
8
# 设置指定RAID组作为第一启动项。
domino:~# ./sas2ircu 0 bootir 322
Avago Technologies SAS2 IR Configuration Utility.
Version 13.00.00.00 (2016.03.08)
Copyright (c) 2009-2016 Avago Technologies. All rights reserved.

SAS2IRCU: Command bootir Completed Successfully.
SAS2IRCU: Utility Completed Successfully.

设置指定单盘作为第一启动项

命令功能
设置指定单盘作为第一启动项。

命令格式

1
sas2ircu `controller_id` bootencl `enclosure_id`:`slot_id`

参数说明

参数 参数说明 取值
controller_id RAID 卡的 ID –
enclosure_id 硬盘所在 Enclosure 的 ID –
slot_id 硬盘槽位号 –

使用指南
无

使用实例

1
2
3
4
5
6
7
8
# 设置指定单盘作为第一启动项
domino:~# ./sas2ircu 0 bootencl 1:4
Avago Technologies SAS2 IR Configuration Utility.
Version 13.00.00.00 (2016.03.08)
Copyright (c) 2009-2016 Avago Technologies. All rights reserved.

SAS2IRCU: Command BOOTENCL Completed Successfully.
SAS2IRCU: Utility Completed Successfully.

sas3ircu

用法同 sas2ircu

问题

辨别 RAID 厂商、型号是个大问题，当前采用严格匹配方式，未适配的型号统统忽略了，比如说下面这些：
58:00.0 RAID bus controller: LSI Logic / Symbios Logic Device 0014 (rev 01)

参考

StorCLI Reference Manual - Broadcom
Disk Controller parameters – Best practice
未完待续…
